Nominal volume: 0.2/0.5/0.7/1/2/3/5/7/10/15 liters Magnetic stirring: diameter to height ratio: 1:2-3; Liquid filling coefficient: 70% Tank body: The lid and bottom of the tank are made of 316L stainless steel, with a stainless steel cooling jacket for easy operation and cleaning; Stainless steel internal polishing accuracy Ra ≤ 0.4; The part in contact with the material is a 316L motor: an AC motor that can operate in harsh environments; Ventilation: The rotary flowmeter displays and adjusts the gas flow according to the process requirements. The stirring system adopts a strong magnetic mechanical suspension magnetic stirring system (fully sealed, zero leakage, pollution-free, changing the dynamic seal into a static seal, completely solving the problem of bacterial infection in biological product tanks); There is no top needle at the bottom, and the stirring speed is 0-1000rpm; Mixing form: straight blade stirring paddle (second stage), mechanical compression defoaming paddle (first stage), fermentation pH control function: using intelligent PID control, dedicated PH electrode; Fermentation dissolved oxygen control function: adopting intelligent PID control and dedicated DO electrode; Temperature control: Large area stainless steel jacket ensures sufficient heat exchange area, electric heating, water cooling, and has good heat exchange efficiency; Cooling water+5~65 ℃, ± 0.2 ℃, resolution 0.1 ℃. Supplementing: A complete replenishment system for sterilization: the sterilization pot is out of position for sterilization; BLBIO-B control system optional: The biological process controller is composed of a wellhead industrial control computer and I/O channels as the core, using a 10 "LCD display as the display interface, with rich and complete display content. The system has multiple related controls: speed and dissolved oxygen related control, feeding and dissolved oxygen related control, feeding and pH value related control, etc. The system has real-time display of the operating process, data and recording, data analysis (bar chart, curve chart and batch report), output printing, password management, abnormal analysis and other functions, with a Chinese interface. The recording screen can display multiple different curves at the same time, and if needed, more curves can be displayed at once. It can select any number of curves from different fermentation batches to be displayed simultaneously for comparative analysis; The parameters of each detection and control circuit can be manually set and corrected online on the screen, and temperature can be adjusted The setting and calibration of DO and PH sensors, calibration of the flow rate of each peristaltic pump, and password protection function for operation.

技术参数：混合速度：转速：0～1000转/分，无级变速；精度：±1转/分；pH值控制：显示范围：0.00～14.0ph±0.01ph，全自动控制范围:2.00-12.00ph，控制精度:分辨率:分辨率:DO控制：可与速度相关联；范围：0.1～150%，控制精度：±3%；分辨率：0.1%；温度控制：适用范围：冷却水温度+5-65℃；精确度：±0.2℃；分辨率：0.1泡沫控制：电极检测，蠕动泵补充消泡剂，自动控制；通风：手动调节，流量计显示；油箱压力：手动调节，压力表显示；范围：0~0.20地图

添加可选功能：

B补充平衡称重W罐称重D自动气流控制E罐压力检测F旁路纯氧g氧化还原电位h的在线检测在线检测与控制A（B）尾气中酒精含量O2 CO2含量在线检测A自动杀菌功能C自动清罐功能U型罐盖自动升降功能

型号注解:BLBIO XABC-D

X-油箱总容积:

A - Tank material: - G: glass/- S: stainless steel - C animal cell tank - V vaccine tank - M enzyme reactor

B-传动方式:-C:磁力驱动机械搅拌/-J直驱机械搅拌/-Q气流搅拌-S固体搅拌-L提供光源

C--增加可选功能--A自动灭菌--无需手动灭菌--Y玻璃原位手动灭菌--U罐盖自动升降

D -控制器型号- A 是工业控制计算机+控制模块-无 B 型控制器，这是我们公司标准控制器- C 是一款 10 英寸液晶触摸屏
